Roller Blind Measuring

For fitting inside the window recess:

Measure the full width and height of the recess area from wall to wall.

Inside Recess Measuring Guide:

• Take three width measurements across the inside of the recess – at the top, middle and bottom.
• Take three height measurements – on the left, in the centre, and on the right.
• Always use a steel tape measure for accurate results in centimetres, measured to the nearest millimetre.
• Record all three measurements (width and height) and use the smallest figure when placing your order.
• The factory will make any necessary deductions for “recess specified blinds” so they fit correctly.
• Check for obstructions such as tiles, handles or rails when measuring, making sure the measurements are accurate.

For fitting outside the window recess:

We will manufacture the blind to the exact measurements you provide, with no deductions.

Outside Recess Measuring Guide:

• Measure the width of the area you would like the blind to cover.
• To block sunlight effectively, we recommend an overlap of around 6 cm on each side and 7 cm at the top.
• Consider any obstructions such as tiles or rails before deciding the final position.
• It is your choice whether to allow an overlap at the bottom of the window.

Please choose one of the following:

Top mount: Fixed to an overhead surface, such as the ceiling or the top of the window recess.

Face mount: Fixed to the wall surface outside the window frame.

When fitting, make sure the brackets are positioned so the blind operates freely and does not touch window handles, doors or other obstructions. Hold the brackets in place with the blind loosely positioned to check alignment and ensure it is centred.

Position the control side bracket on the same side as the blind’s control mechanism. Mark where the first bracket will go, ensuring it is level and straight. Drill the holes and fix the bracket securely, using raw plugs if attaching to a wall.

Insert one end of the blind into the mounted bracket. Place the other bracket at the opposite end, mark its position, and make sure it lines up level with the first. Drill the holes and fix the second bracket into place, again using raw plugs if needed.

Mounting the Blind

Insert the pin side of the blind into the pin side bracket. This end has a spring function to make fitting and removing the blind easier. Place the control mechanism into the control side bracket as shown. The central lug on the mechanism should face downwards, fitting securely into the bracket slot.

Operating the Blind

Once the blind has been installed, simply use the side chain to raise and lower it smoothly.

P-Clip Safety Device

The P-clip must be fitted as far away as possible from the control mechanism to stop the looped chain from hanging loosely.

• Place the control chain inside the P-clip.
• Ensure the chain is tight and that the P-clip is fixed at the bottom of the loop.
• Make sure the chain moves freely while remaining tight.
• Screw the tensioning device into the wall, directly in line with the blind, to keep the chain permanently secure and under constant tension.
