Roller Blind Only Measurement

For fitting the blind inside a window recess, measure the full width and height of the recess (wall to wall).

Inside Recess Measurement

• Take three width measurements across the window recess: top, middle, and bottom
• Take three height measurements: left, middle, and right

Guide for Inside Recess Fitting

• Use a steel tape measure for accuracy, in centimetres to the nearest millimetre
• Measure in three specific places for both width and height, using the smallest measurement for ordering
• The factory will make any necessary deductions for recess-specified blinds to ensure a perfect fit
• Be careful of obstacles such as tiles, handles, or rails to ensure the position is accurate

Outside Recess Measurement

For blinds fitted outside the recess, the blind will be made to your exact measurements with no deductions.

Guide for Outside Recess Fitting

• Measure the exact area you want the blind to cover
• To prevent sunlight from entering, allow an overlap of 6 cm on each side and 7 cm above the window
• You may also choose to overlap at the bottom of the window
• Take care around obstacles such as tiles or rails to ensure correct positioning

Please select:

Top Mount: Fitted to an overhead surface, such as the top of the window recess or ceiling.

Face Mount: Fitted to the surface outside the window frame.

Fitting Instructions:

• Position the brackets so the blind can operate freely, without touching handles or frames
• Place both brackets loosely on the blind and position them in the window to help with centring
• Attach the control side bracket on the same side as the chain or motor mechanism. Ensure it is level, mark the position, drill holes, and fix with raw plugs if attaching to a wall
• Insert one end of the blind into the mounted bracket, then mark the position of the other bracket on the opposite end. Ensure it is level, drill, and secure with raw plugs

Mounting the Blind

• Insert the pin end of the blind into the pin bracket. The pin end has a spring mechanism for easy mounting and removal
• Insert the control mechanism into the control side bracket. The central lug should face downwards and fit into the bracket cross-section to lock into place

Operating the Blind

• Once installed, operate the blind using the remote or the chain at the side

P-Clip Safety Device

• Install the P-clip as far as possible from the control mechanism to keep the chain tight
• Ensure the control chain is placed inside the P-clip and positioned at the bottom of the loop for smooth operation
• Secure the tensioning device to the wall, aligned with the blind, to maintain chain tension
• The chain will remain permanently taut and safe under constant tension
