Roller Only Measure

For blinds fitted inside a window recess, measure the full width and height of the recessed area (wall to wall).

Inside Recess Measurement

• Measure across the top, middle, and bottom of the recess.
• Measure vertically at the left, centre, and right of the recess.

Guide for Inside Recess Fitting

Use a steel tape measure for accurate measurements in centimetres to the nearest millimetre. Measure width and height in three positions and use the smallest measurement when ordering. The factory will make any necessary deductions for recess blinds to ensure a perfect fit. Be careful of obstructions like handles, tiles, and rails.

Outside Recess Measurement

For blinds fitted outside the recess, we make them to the exact measurements provided, with no deductions.

Guide for Outside Recess Fitting

To block sunlight effectively, we recommend an overlap of 6cm on each side and 7cm at the top. Measure the exact width of the area. Be mindful of obstructions such as rails or tiles. Overlapping at the bottom is optional.

Please choose your preferred mounting method:

• Top mount: fixed to the ceiling or top of the window recess.
• Face mount: fixed to the face of the outside window frame.

Position the brackets so the blind can operate freely without hitting handles or the window. Place the brackets loosely on the blind and hold it in place to check alignment. This will help you mark the correct positions.

Place the control-side bracket on the same side as the chain or motor mechanism. Mark the first bracket’s position, ensuring it is level and straight to prevent malfunction. Drill the holes and fix the bracket securely, using raw plugs if attaching to a wall.

Insert one end of the blind into the mounted bracket. Position the other bracket at the opposite end, ensuring it is level with the first. Drill and fix the second bracket securely.

Mounting the Blind

Insert the pin end of the blind into the pin bracket. The spring-loaded pin makes mounting and removal easier. Fit the control mechanism into the control-side bracket, making sure the central lug points downward and hooks securely into the bracket.

Operating the Blind

Once installed, use the side chain or remote control to raise and lower the blind.

P-Clip Safety Device

Install the safety device as far from the control mechanism as possible to prevent the chain from going slack.

Ensure the chain passes through the P-clip, remains tight, and moves freely. The P-clip should sit at the bottom of the loop. Secure the tensioning device to the wall, keeping the chain under constant tension so it remains permanently tight and safe.
