Tools You Will Need to Measure Vertical Blinds:

• Steel tape measure
• Pencil for marking and writing measurements
• Worksheet to record your findings
• Ladder if your windows are tall

Tips for Accurate Measurements:

• Do not confuse height and width measurements, as swapping them can lead to a blind that does not fit properly.
• If measuring multiple windows, do not assume they are the same size. Measure each window individually, as even slight differences can affect the blind’s fit.

Outside Recess Measurement

Measure the exact area you want the blind to cover. To reduce light leakage, the blind should extend at least 70mm above the window recess and 50mm on each side. The bottom overlap is optional, but consider obstacles such as radiators. Use a metal tape measure, as cloth tapes can stretch and give inaccurate results.

Inside Recess Measurement

For an inside recess fit, measure the full width and height of the window recess (the opening of the window). We will make the necessary adjustments to ensure a perfect fit. Measure width and height in three different places and use the smallest measurement. Do not make any deductions yourself; we will handle this to guarantee accuracy. Always use a metal tape measure for precision.

Ensure you have all the components supplied with your vertical blind. You will also need:

Additional Equipment:

• Top fix brackets x2
• Face fix brackets x2
• Hangers x1
• Allen key x1
• Stabilising chain x2
• Safety hook x1
• Wood screws x4
• Weight x1
• Pencil
• Screws
• Drill with suitable bits
• Crosshead screwdriver
• Metal tape measure

Face Fixing Instructions

Position the brackets approximately 5cm from each end where the headrail will be placed. If there are more than two brackets, space the extra ones evenly along the length of the blind. Ensure the fixings are suitable for the wall or surface. Hook the back of the headrail into the bracket and rotate it into position. Secure the headrail by tightening the small screw at the front of the bracket.

Top Fixing Instructions

Measure and mark the bracket positions, allowing clearance for window handles or other obstacles. Place the brackets about 10cm from each end. Space any extra brackets evenly along the blind. Ensure the fixings are appropriate for the wall or surface. Tilt the headrail and hook it into the bracket, then rotate it until it clicks. To release the headrail, press the bracket at the designated point.
