When measuring for slat replacement only, the size will cover the fabric length of the vertical blind when laid flat. The common slat width is 89mm, which is also the standard size for most available fabrics.

When placing your order, make sure the fabric you choose has the correct width. Always measure to the nearest centimetre. Do not make any deductions to the width or drop measurements.

Measuring Slats

If slats are not available, follow these steps:

• Measure the exact size you need at your window.
• Take the measurement from the track opening down to where you would like the slat to finish.
• Ensure the slat ends around 13mm above any obstruction, such as a window sill or radiator.

Counting Slats:

• Count your current slats or the number of track hooks on your headrail.
• When ordering, type in the total quantity you require.

Make sure you have the following parts supplied with your vertical blind:

• Top fix brackets ×2
• Face fix brackets ×2
• Hangers ×1
• Allen key ×1
• Stabilising chains ×2
• Safety hook ×1
• Wood screws ×4
• Weights ×1
• Pencil
• Screws
• Drill with suitable drill bits
• Cross-head screwdriver
• Metal tape measure

Face Fix

Position the brackets around 5cm from both ends of where the headrail will be fitted. If more than two brackets are included, spread the extra ones evenly across the length of the blind. Always make sure the fixings are suitable for the surface you are attaching them to.

To fit, hook the back of the headrail into the bracket, rotate the headrail into place, and secure it by tightening the small screw at the front of the bracket.

Top Fix

First, check and mark the distance needed to avoid obstacles like window handles that project into the recess. Place the brackets around 10cm from each end of the headrail position to make sure the handle can clear. If more than two brackets are provided, fix the rest evenly across the blind’s length. Ensure all fittings are suitable for the mounting surface.

To install, tilt and hook the headrail into the bracket. Rotate it until it clicks into position. To remove the headrail, press the bracket release point.
