For Roller Blinds Only

Inside Recess Measurement

To fit your blind inside the window recess, measure the full width and height of the recessed area, from wall to wall.

1. Take three measurements across the window recess at the top, middle, and bottom.
2. Take three measurements vertically at the left, right, and centre.

Guide for Inside Recess Fitting:

• Use a steel tape measure for precise measurements in centimetres to the nearest millimetre.
• Measure width and height in three places and use the smallest measurement for ordering.
• The factory will make any necessary deductions for recess blinds to ensure a perfect fit.
• Take care when measuring around obstructions such as tiles, handles, or rails to ensure accurate results.

Outside Recess Measurement

If the blind is to be fitted outside the recess, it will be made exactly to your specified measurements with no deductions.

Guide for Outside Recess Fitting:

• To block sunlight effectively, we recommend an overlap of 6cm on each side and 7cm at the top.
• Measure the exact width of the area you wish to cover.
• Take care when measuring around obstacles such as tiles or rails.
• You may choose whether to overlap the bottom of the window.

Please select your preferred mounting method:

Top Mount: Fit to the ceiling or the top of the window recess.

Face Mount: Fit to the outside face of the window frame.

• Position the brackets so that the blind can operate freely without hitting door handles or window frames.
• Place both brackets loosely on the blind and position it in the window to check alignment. This will make it easier to centre the blind correctly.

1. Place the control-side bracket on the same side as the chain mechanism. Mark its position carefully, ensuring it is level and straight. Drill holes and secure the bracket with raw plugs if fixing to a wall.
2. Insert one end of the blind into the mounted bracket. Position the second bracket at the other end, mark it level with the first, and drill and secure it using raw plugs if needed.

Mounting the Blind:

• Insert the pin side of the blind into the pin-side bracket. The pin end has a spring mechanism for easy mounting and removal.
• Insert the control mechanism into the control-side bracket, ensuring the central lug points downward and hooks securely into the bracket.

Operating the Blind

Once installed, use the side chain to raise and lower the blind smoothly.

P-Clip Safety Device

• Install the P-clip as far away from the control mechanism as possible to prevent the chain from becoming slack.
• Ensure the chain passes through the P-clip and sits tightly at the bottom of the loop.
• Fix the tensioning device securely along the wall from one end to the other to maintain constant tension. This keeps the chain tight and ensures safe and smooth operation.
