Roller Only Measurement

To fit the blind inside a window recess, measure the full width and height of the recess from wall to wall.

Inside Recess Measurement

• Take three width measurements across the top, middle, and bottom of the recess.
• Take three height measurements down the left side, centre, and right side of the window.

Guide for Inside Recess Fitting

• Use a steel tape measure to get accurate measurements in centimetres to the nearest millimetre.
• Measure in three locations for both width and height, and use the smallest measurement when placing your order.
• The factory will make any necessary deductions for recess-specified blinds to ensure a perfect fit.
• Be careful of obstructions such as tiles, window handles, or rails when measuring.

Outside Recess Measurement

For blinds that are fitted outside the window recess, they will be made to your exact measurements with no deductions.

Guide for Outside Recess Fitting

• Measure the full area you want the blind to cover. To reduce sunlight entering the room, it is recommended to overlap by approximately 6 cm on each side and 7 cm above the window.
• Take care with any obstructions, such as tiles or window rails, to ensure accurate measurements.
• You may decide whether to allow the blind to overlap at the bottom of the window.

Please select one of the following mounting methods:

• Top Mount: The blind is mounted to an overhead surface, such as the top of the window recess or the ceiling.
• Face Mount: The blind is mounted to the front of the window frame on the outside.

To ensure the blind operates freely, position the brackets so that the blind does not touch handles, window frames, or other objects. Loosely attach both brackets to the blind and position it in the window to check placement and alignment.

Place the control-side bracket on the same side as the chain mechanism. Mark the bracket’s position carefully, making sure it is level and not twisted, as this could affect the blind’s operation. Drill holes and fix the bracket in place, using raw plugs if attaching to a wall. Insert one end of the blind into this bracket. Position the second bracket on the opposite end, mark its position, ensure it is level with the first, drill holes, and secure it in place.

Mounting the Blind

Insert the pin end of the blind into the pin-side bracket. The spring mechanism on this side allows easy mounting and removal of the blind. Place the control end into the control-side bracket, ensuring the central lug points downward and slots securely into the cross-section of the bracket.

Operating the Blind

Once the blind is installed, use the side chain to raise and lower it smoothly.

P-Clip Safety Device

The P-clip must be fitted as far from the control mechanism as possible to prevent the looped chain from becoming slack.

• Ensure the chain passes inside the P-clip.
• Keep the chain tight, with the P-clip positioned at the bottom of the loop.
• Secure the tensioning device to the wall in line with the blind, so that the chain remains tight and operates smoothly.
• This will keep the chain permanently tight and under constant tension.
